Output voltage at 1 kHz 5 cm/sec – 0.45 mV
Frequency range at -3 dB – 20 Hz – 50 kHz
Frequency response 20 Hz – 20 kHz – +3/-1
Tracking ability at 315 Hz at recommended tracking force *) – 70 μm
Compliance, dynamic, lateral – 12 μm/mN
Stylus type – Nude Fine Line on Alu cantilever
Stylus tip radius – r/R 8/40
Tracking force range – 2.2-2.7 g (22-27 mN)
Tracking force recommended – 2.5 g (25 mN)
Tracking angle – 20º
*) Typical value
Internal impedance, DC resistance – 5 Ohm
Recommended load impedance – 50-500 Ohm
Cartridge body material – Stainless steel Aluminium
Cartridge colour – Natural/Black
Cartridge weight – 10.7 gram
