Output voltage at 1 kHz 5 cm/sec – 0,45 mV
Channel balance – < 1,5 dB Channel separation at 1 kHz – > 23 dB
Channel separation at 15 kHz – > 15 dB
Frequency range at -3 dB – 20 Hz – 50 kHz
Frequency response 20 Hz – 20 kHz – +3/-1
Tracking ability at 315 Hz at recommended tracking force *) – 80 μm
Compliance, dynamic, lateral – 12 μm/mN
Stylus type – Nude Fine Line on Alu cantilever
Stylus tip radius – r/R 8/40
Tracking force range – 2,2-2,7 g (22-27 mN)
Tracking force recommended – 2,5 g (25 mN)
*) Typical value
Tracking angle – 20º
Internal impedance, DC resistance – 5 Ohm
Recommended load impedance – 50-500 Ohm
Cartridge body materia – Stainless steel Aluminium
Cartridge colour – Red/Black
Cartridge weight – 10,7 gram
